Andrena 12V 10Ah – LiFePO4 Battery
The Andrena 12V 10Ah is a lithium iron phosphate battery engineered for motorsports applications requiring 12V system compatibility in extreme environments. Standard rally casing design with IP69 water rating and operational range from -30°C to 55°C.
The Andrena 12V 10Ah delivers 10Ah nominal capacity at 12.8V nominal voltage. LiFePO4 chemistry provides over 1,000 charge-discharge cycles with self-discharge below 3% per month. Compact cylindrical design measures 120 x 82 x 124 mm and weighs 1.7 kg.
IP69 water rating ensures operation in high-pressure wash environments. Operating temperature range spans -30°C to 55°C. Fast charging capability supports rapid deployment cycles. Suitable for rally, motorsport, and off-road vehicle applications.
APPLICATIONS
Primary use cases.
Motorsports & Rally
Primary application for high-vibration, extreme-temperature motorsport environments
Off-Road Vehicles
Suitable for 12V systems in vehicles requiring robust power in harsh conditions
High-Pressure Wash Environments
IP69 rating enables operation in wet, high-pressure wash bay conditions
TECHNICAL DATA
Complete specifications and tolerances for the Andrena 12V 10Ah – LiFePO4 Battery.
| PARAMETER | SPECIFICATION |
|---|---|
| Product | Andrena 12V 10Ah |
| Chemistry | Lithium Iron Phosphate (LiFePO4) |
| Nominal Voltage | 12.8V |
| Nominal Capacity | 10Ah |
| Dimensions | 120 x 82 x 124 mm |
| Weight | 1.7 kg |
| Water Rating | IP69 |
| Operating Temperature | -30°C to +55°C |
| Charge-Discharge Cycles | >1,000 |
| Self-Discharge Rate | <3% per month |
REGULATORY COMPLIANCE
Validated by the world's leading maritime classification societies.
European Conformity
Product meets EU safety and performance standards
38.3
Lithium battery transport classification and safety requirements
1642 (Cells)
Lithium battery cell safety standard certification
TECHNICAL FAQ
Common specifications and regulatory inquiries.
What is the cycle life of the Andrena 12V 10Ah?
What is the self-discharge rate?
Can this battery operate in cold environments?
What water protection does the Andrena provide?
Is fast charging supported?
What certifications does this battery hold?
