Andrena 12V 20Ah-SC – LiFePO4 Battery
The Andrena 12V 20Ah-SC is a lithium iron phosphate battery engineered for motorsports applications requiring 12V system compatibility in extreme environments. Cylindrical cell configuration with standard rally casing delivers 20Ah nominal capacity, IP69 water rating, and operational range from -30°C to 55°C.
The Andrena 12V 20Ah-SC is a lithium iron phosphate battery engineered for motorsports applications requiring 12V system compatibility in extreme environments. Cylindrical cell configuration with standard rally casing delivers 20Ah nominal capacity, IP69 water rating, and operational range from -30°C to 55°C.
Key performance metrics: self-discharge rate below 3% per month, cycle life exceeding 1,000 charge-discharge cycles, 12.8V nominal voltage output, and compact dimensions of 249 × 96 × 141 mm at 2.9 kg total weight. Fast charging capability supports rapid deployment in motorsport operations.
APPLICATIONS
Primary use cases.
Motorsports
Rally vehicles and motorsport platforms requiring lightweight, high-cycle-life power systems with extreme temperature tolerance.
Off-Road Vehicles
Applications demanding IP69 water ingress protection and operational performance across -30°C to 55°C environmental conditions.
TECHNICAL DATA
Complete specifications and tolerances for the Andrena 12V 20Ah-SC – LiFePO4 Battery.
| PARAMETER | SPECIFICATION |
|---|---|
| Product Model | Andrena 12V 20Ah-SC |
| Chemistry | Lithium Iron Phosphate (LiFePO4) |
| Nominal Voltage | 12.8V |
| Nominal Capacity | 20Ah |
| Water Rating | IP69 |
| Operating Temperature | -30°C to +55°C |
| Self-Discharge Rate | <3% per month |
| Cycle Life | >1,000 cycles |
| Dimensions | 249 × 96 × 141 mm |
| Weight | 2.9 kg |
| Cell Configuration | Cylindrical LiFePO4 |
REGULATORY COMPLIANCE
Validated by the world's leading maritime classification societies.
European Conformity
Product meets European Union safety and performance standards.
38.3
Lithium battery transport classification and safety requirements for air and ground shipment.
1642 (Cells)
Underwriters Laboratories standard for safety of lithium battery cells.
TECHNICAL FAQ
Common specifications and regulatory inquiries.
What is the cycle life of the Andrena 12V 20Ah-SC?
What temperature range is this battery rated for?
What is the self-discharge rate?
What water protection rating does this battery have?
What certifications does the Andrena 12V 20Ah-SC hold?
What is the nominal voltage output?
SUPPLEMENTARY FILES
Data Sheets, Manuals, and Technical Specifications.
