Andrena 12V 5Ah – LiFePO4 Battery
LiFePO4 battery rated 12V 5Ah for motorsports applications. Cylindrical cell configuration in rally casing. Operational range -30°C to 55°C with IP69 water rating. Supports 1,000+ charge cycles and <3% monthly self-discharge.
The Andrena 12V 5Ah is a lithium iron phosphate battery engineered for motorsports 12V systems. The unit employs cylindrical LiFePO4 cells housed in a standard rally casing, rated IP69 for water ingress protection.
Performance characteristics include self-discharge below 3% per month, cycle life exceeding 1,000 charge-discharge cycles, and operational temperature range from -30°C to 55°C. Dimensions: 114 × 62 × 84 mm. Weight: 0.85 kg.
APPLICATIONS
Primary use cases.
Motorsports
Primary application for rally vehicles and motorsport platforms requiring compact, high-cycle-life 12V power sources.
Extreme Environment Systems
Suitable for 12V systems operating in temperature extremes and high-moisture conditions due to IP69 rating and wide operational temperature range.
TECHNICAL DATA
Complete specifications and tolerances for the Andrena 12V 5Ah – LiFePO4 Battery.
| PARAMETER | SPECIFICATION |
|---|---|
| Chemistry | Lithium Iron Phosphate (LiFePO4) |
| Nominal Voltage | 12.8V |
| Nominal Capacity | 5Ah |
| Water Rating | IP69 |
| Operating Temperature | -30°C to 55°C |
| Self-Discharge Rate | <3% per month |
| Cycle Life | >1,000 charge-discharge cycles |
| Dimensions | 114 × 62 × 84 mm |
| Weight | 0.85 kg |
REGULATORY COMPLIANCE
Validated by the world's leading maritime classification societies.
CE Marking
Product meets European Union safety and performance requirements.
UN 38.3
Lithium battery transport classification and safety standard compliance.
UL 1642
Lithium battery cell safety certification.
TECHNICAL FAQ
Common specifications and regulatory inquiries.
What is the nominal voltage output?
How many charge cycles does the battery support?
What is the water ingress rating?
What temperature range is supported?
What certifications does this battery hold?
SUPPLEMENTARY FILES
Data Sheets, Manuals, and Technical Specifications.
