Andrena 12V 7.5Ah – LiFePO4 Battery
The Andrena 12V 7.5Ah is a lithium iron phosphate battery engineered for motorsports applications. Built in standard rally casing, it delivers 7.5Ah capacity at 12.8V nominal voltage with operational range from -30°C to 55°C. Rated IP69 for water ingress protection.
The Andrena 12V 7.5Ah is a lithium iron phosphate battery engineered for motorsports applications. Built in standard rally casing, it delivers 7.5Ah capacity at 12.8V nominal voltage with operational range from -30°C to 55°C. Rated IP69 for water ingress protection.
Key performance metrics: self-discharge rate below 3% per month, over 1,000 charge-discharge cycles, and fast charging capability. Cylindrical LiFePO4 cell configuration in compact form factor weighing 1.3 kg. Dimensions: 120 x 82 x 98 mm.
APPLICATIONS
Primary use cases.
Motorsports
Rally and motorsport vehicles requiring compact, high-cycle-life power systems in extreme temperature environments
12V Systems
Standard 12V electrical systems requiring lithium-based energy storage with extended operational temperature range
TECHNICAL DATA
Complete specifications and tolerances for the Andrena 12V 7.5Ah – LiFePO4 Battery.
| PARAMETER | SPECIFICATION |
|---|---|
| Product Name | Andrena 12V 7.5Ah |
| Nominal Voltage | 12.8V |
| Nominal Capacity | 7.5Ah |
| Chemistry | Lithium Iron Phosphate (LiFePO4) |
| Dimensions | 120 x 82 x 98 mm |
| Weight | 1.3 kg |
| Operating Temperature | -30°C to +55°C |
| Water Rating | IP69 |
| Self-Discharge Rate | <3% per month |
| Charge-Discharge Cycles | >1,000 cycles |
REGULATORY COMPLIANCE
Validated by the world's leading maritime classification societies.
CE Marking
Conforms to European Union safety and performance standards
UN 38.3
Lithium battery transport classification and safety requirements
UL 1642
Lithium battery cell safety standard
TECHNICAL FAQ
Common specifications and regulatory inquiries.
What is the nominal voltage output?
What is the operational temperature range?
How many charge cycles does the battery support?
What is the self-discharge rate?
What is the water ingress rating?
What certifications does this battery hold?
SUPPLEMENTARY FILES
Data Sheets, Manuals, and Technical Specifications.
