The WMFC PA Plastic Frame is a lightweight mounting solution for cable transits in data centers, automation, cabinets, and marine applications. Constructed from PA 6.6 reinforced with 30% glass fill, the flanged design accommodates installation around existing cables and pipes without removal.
The WMFC PA Plastic Frame provides a flanged mounting solution for cable and pipe transits. The frame is engineered for installation in environments where cabling or piping infrastructure is already in place, eliminating the need for removal of existing systems.
Material composition: PA 6.6 with 30% glass reinforcement delivers structural integrity while maintaining lightweight characteristics. Suitable for data centers, automation systems, cabinet installations, and marine environments.
APPLICATIONS
Primary use cases.
Data Centers
Cable transit management in server rack and infrastructure installations.
Automation Systems
Cable and pipe routing in industrial automation control cabinets.
Marine Applications
Corrosion-resistant cable management for marine vessel installations.
Cabinet Installations
Retrofit cable management where existing infrastructure cannot be disturbed.
TECHNICAL DATA
Complete specifications and tolerances for the WMFC Plastic Frame – WallMax.
| PARAMETER | SPECIFICATION |
|---|---|
| Part Number | 71 1316 1811 |
| Material | PA 6.6, 30% glass filled |
| Frame Type | Rectangular, flanged |
| Dimensions | 420 × 320 mm |
| Weight | 1.78 kg |
| Packing Dimensions | 180 × 120 mm |
