Xenon Prison Grade Searchlights – Francis FX380RC
The Francis FX380RC is a 500W Xenon remote-controlled searchlight designed for marine, border security, and high-latitude operations. Operating via the FBUS RS485 protocol, it delivers a beam distance of 5,290 meters at 1 Lux, variable speed motion, and full functionality in temperatures down to -50 degrees
Engineered for reliable performance in harsh operating environments, the Francis FX380RC incorporates a 500W Xenon light source and a parabolic glass reflector to deliver 28,000,000 Peak Beam Candle Power (PBCP). The color temperature replicates natural daylight, making it suitable for optical clarity in polar conditions. An instant re-strike feature allows immediate re-ignition without lamp cooling delays.
The searchlight assembly is constructed from marine-grade materials with a powder-coated stove enamel finish and toughened Optiwhite front glass. Motion is managed via a modern membrane joystick panel utilizing the two-wire bi-directional RS485 Francis Bus (FBUS) system. The pan mechanism provides 385∘ rotation at speeds up to 23∘/sec, while the tilt elevation spans +30∘ to -35∘ at speeds up to 8∘/sec. Barrel and gearbox heating elements maintain mechanical mobility in low-temperature operations down to -50∘C. The unit includes a high-efficiency electronic power supply unit (PSU) compatible with 115V or 230V single-phase supplies at 50/60 Hz.
APPLICATIONS
Primary use cases.
Polar and High-Latitude Navigation
The Xenon light source replicates natural daylight spectrum for optimal contrast against ice formations, while the integrated internal gearbox heater ensures operation at temperatures as low as -50 degrees C
Commercial Marine Security and Border Patrol
FBUS RS485 integration permits multi-control configurations and high-speed variable pan/tilt tracking for monitoring moving vessels or hazards.
Coastal and Search & Rescue (SAR) Operations
Provides long-range target identification up to 5,290 meters @ 1 Lux, with instant re-strike capability ensuring uninterrupted operation
Perimeter and Critical Infrastructure Security
Supports remote networked control via TCP/IP or master-slave panels, enabling automated sweeps and integration into site security architectures.
TECHNICAL DATA
Complete specifications and tolerances for the Xenon Prison Grade Searchlights – Francis FX380RC.
| PARAMETER | SPECIFICATION |
|---|---|
| Part Number | A7160 (230V / A7159) 115V |
| Lamp Type / Power | 500W Xenon (Part No. D20322) |
| Supply Voltage | 115V or 230V single Phase VAC |
| Lamp Life | 2,500 Hours |
| Range @ 1 Lux | 5,290 meters |
| Peak Beam Candle Power (PBCP) | 28,000,000 |
| Divergence / Beam Angle | 1.5 spot to 10 flood (remote adjustable) |
| Pan Rotation Range | 385 |
| Pan Rotation Speed | Variable 1 to 23 degrees per second |
| Tilt Elevation Range | +30, -35 degrees |
| Communications Protocol | FBUS (RS485 two-wire bi-directional) |
| Mounting / Base Fixing | 4 x 12.5 mm holes equi-spaced on a 350 mm PCD |
| Searchlight Weight | 53 kg |
| Front Glass Type | Toughened Optiwhite glass |
| Reflector Type | Parabolic Glass |
REGULATORY COMPLIANCE
Validated by the world's leading maritime classification societies.
66
Power Supply Unit (PSU)
66
Gearbox
56
Searchlight Body
TECHNICAL FAQ
Common specifications and regulatory inquiries.
Q: How many searchlights can be controlled from a single master control panel?
Where can the Power Supply Unit (PSU) be installed?
Does the FX380RC support programmatic or automated positioning routines?
