Xenon Searchlights – Francis FX480
2,000W xenon searchlight for marine and security applications. Delivers 9,500m range with immediate full brilliance and instant re-strike capability. IP66 sealed housing in marine-grade stainless steel.
The Francis FX480 is a 2,000W xenon searchlight engineered for demanding maritime and security operations. The unit features a parabolic aluminum reflector with toughened front glass, delivering long-range illumination without cooling-down periods between strikes.
Applications include collision avoidance, man-overboard detection, and perimeter security. The searchlight achieves full lamp brilliance on switch-on and supports pan rotation of 450°. Barrel-mounted heater maintains performance in cold environments. Remote focus control is available as an optional upgrade.
APPLICATIONS
Primary use cases.
Marine Operations
Collision avoidance, man-overboard search and rescue, vessel navigation and docking procedures.
Security and Surveillance
Perimeter illumination, facility security, and long-range threat detection.
TECHNICAL DATA
Complete specifications and tolerances for the Xenon Searchlights – Francis FX480.
| PARAMETER | SPECIFICATION |
|---|---|
| Power Output | 2,000W |
| Voltage Input | 115V / 240V AC |
| Lamp Life | 3,000 hours |
| Effective Range | 9,500m |
| Material | Marine-grade stainless steel |
| Reflector | Parabolic aluminum |
| Pan Rotation | 450° |
| Front Lens | Toughened glass |
| Housing Rating | IP66 |
| PSU Rating | IP44 |
REGULATORY COMPLIANCE
Validated by the world's leading maritime classification societies.
IP66 / IP44
Searchlight housing rated IP66 (dust and water jet protection). Power supply unit rated IP44 (splash protection).
TECHNICAL FAQ
Common specifications and regulatory inquiries.
What is the re-strike time?
Is remote focus available?
What protection does the heater provide?
Can dimensions be customized?
What is the lamp life expectancy?
SUPPLEMENTARY FILES
Data Sheets, Manuals, and Technical Specifications.
